1.5" Socket Tee

4" MS Elbow B Class Price : 250.0 INR/Piece Minimum Order Quantity : 10 Material : Other , Mild Steel (MS) Surface Treatment : Other, Black Painted / AntiRust Coated Product Type : Other, Pipe Fitting Elbow Section Shape : Round Color : Black Material Grade : IS 1239 / Equivalent Standard : Other, IS 1239 B Class Application : other, Pipe Fitting for Direction Change Temperature Range : Up to 400C Diameter : 4 Inch (nominal bore) Tolerance : 1 mm Thickness : 5.4 mm (as per B Class for 4 pipe) Connection Type : Welded Shape : Other, Elbow (90 Degree) Sealing Type : Welded Joint Connection : Other, Butt Weld Length : Custom / Standard Lengths Flexibility : Rigid Usage : Plumbing, Gas, Water Supply, Industrial Piping Tensile Strength : 350 MPa Rated Pressure : Up to 25 bar (varies by use) Outer Diameter : 114.3 mm Yield Strength : 250 MPa Thread Type : Not Threaded Bend Radius : 1.5D (typically 168 mm) Coating Type : Standard Black Paint

Forged Fittings Price : 110 INR/Piece Minimum Order Quantity : 100 Material : Stainless Steel Surface Treatment : Other, Black, Galvanized, Antirust Oil Product Type : Other, Forged Fittings Section Shape : Round Color : Silver, Black Material Grade : SS304, SS316, A105, A182 F11/F22/F304/F316, LF2 Standard : Other, ASTM A105, ASTM A182, ASTM A350, MSS SP79, MSS SP83, ASME B16.11 Application : other, Oil & Gas, Petrochemical, Power Plant, Chemical, Water Supply Temperature Range : 20C to 600C Diameter : 6 mm to 100 mm Tolerance : +/ 0.01 mm Thickness : Sch 10 to Sch XXS Connection Type : Screwed, Welded Shape : Other, Elbow, Tee, Coupling, Cross, Union, Cap, Plug, Nipple Sealing Type : Metaltometal, Threaded Sealing Connection : Other, Threaded, Socket Weld Length : As per Standard or Custom Flexibility : Rigid Usage : Industrial Pipe Connection Tensile Strength : 485 MPa (for SS), 485 MPa (for CS) Rated Pressure : 2000LBS, 3000LBS, 6000LBS, 9000LBS Outer Diameter : 1/8 to 4 (DN6 DN100) Yield Strength : 250 MPa (for SS), 250 MPa (for CS) Thread Type : NPT, BSP, BSPT, Metric Bend Radius : Based on Fitting Type Coating Type : Zinc, Phosphating, Anticorrosive

MS Pipe Socket Price : 50 INR/Unit Minimum Order Quantity : 20 Material : Mild Steel Surface Treatment : Other Product Type : Other Section Shape : Round Color : Black / Silver (Galvanized) Material Grade : MS (Gr A / B / C) Standard : Other, IS 1239 / IS 3589 Application : other, Pipe Fitting / Joining Two Pipes Temperature Range : 10C to +150C Diameter : 15 mm to 150 mm Tolerance : 0.5 mm Thickness : 2.5 mm 8 mm Connection Type : Screwed / Socket Weld Shape : Round Sealing Type : Threaded or Welded Joint Connection : Other, Socket Weld / Threaded Length : 50 mm 150 mm Flexibility : Rigid Usage : Industrial / Plumbing / Gas Pipeline Tensile Strength : Up to 350 MPa Rated Pressure : Up to 25 bar Outer Diameter : 15 mm 150 mm Yield Strength : Up to 250 MPa Thread Type : BSP / NPT Coating Type : Galvanized / Black Painted

Pipe Tee Price : 350 INR/Unit Minimum Order Quantity : 20 Material : Mild Steel Surface Treatment : Other Product Type : Tee Section Shape : Round Color : Silver Material Grade : SS304 Standard : Other, ASTM A403 Application : other, Oil & Gas, Chemical Processing, Water Line Temperature Range : 20C to 220C Diameter : 50 mm Tolerance : 1% Thickness : 4 mm Connection Type : Welded Shape : Other Sealing Type : Metal to Metal Connection : Other, Butt Weld Length : 75 mm Flexibility : Rigid Usage : Plumbing, Water Supply, Industrial Pipe Fitting Tensile Strength : 520 MPa Rated Pressure : 16 bar Outer Diameter : 50 mm Yield Strength : 210 MPa Bend Radius : As per standard
